Overview

Looking for an ultrasonic ranging sensor that is waterproof?

This sensor can be operated in 2 modes, mode 1 is a pulsed mode in this mode it will work like most of the ultrasonic sensors on offer for Arduino projects. In mode 2 it is in a serial mode and you can communicate to the sensor with a UART and all the complexities of timing will be handled by the sensor.

Also take note this sensor only makes use of a single transducer unlike some of the other sensors available on the market where there is a RX and a TX transducer.

Specifications

Description:

• Voltage: DC 3 ~ 5.5V
• Quiescent current: < 8mA
• Frequency: 40khz
• Detection range: 20cm to 600cm
• Accuracy: ± 1cm
• Resolution: 1mm
• Measuring angle: 75 degrees
• Size: L42 * W29 * H12 mm
• Working temperature: -20 ℃ - +70 ℃
